Behringer GRIND - Specifications

242 243Quick Start Guide
GRIND
Specications
Synthesizer Architecture
Number of voices Monophonic
Type Hybrid Analog / Digital
Oscillators 1 Digital Modelling
LFO 1 (0.01 Hz to 350 Hz)
VCF 1 low pass 24 dB/octave slope
Envelope 1 ADS
Connectivity
Power Input DC 12 V 1000 mA
Power Switch Push button on/o
MIDI 5 pin DIN In Out/Thru
USB Class compliant 2.0 Type B
Outputs
3.5 mm TS jack socket, unbalanced, Max +8 dBu
1 kΩ impedance
Headphones 3.5 mm TRS, max 10 mW @ 32 Ω
Modelling Oscillator
Buttons Bank select, Model Select
Controls
Timbre, Timbre CV attenuator, Harmonics, FM, Frequency,
Morph, Morph CV attenuator
VCF
Controls
Cuto Frequency (20 Hz to 20 kHz), Resonance,
ModulationDepth
Switches
Lo pass/Hi pass, Modulation source (env/LFO),
Modulationpolarity (positive/negative)
VCA
Control Volume
Switch Mode (envelope, LPG, on)
Envelope
Controls Attack (2 ms to 3 s), Decay (2 ms to 5 s), Sustain
Vibrato
Control Osc Modulation
Modulation
Control LFO Rate
Switch LFO shape (square, triangle)
LED LFO Rate
Utility
Controls Glide, VC mix
Sequencer/Arpeggiator
Steps 32 per pattern
Patterns 64
Memory 8 banks of 8 patterns
Controls Tempo/Gate length/Swing
Switches
Hold/Rest, Reset/Accent, Arp/Set End, Pattern/Bank, Shift,
Page, Play/Stop, Rec, Keyboard, Step, 13 note ‘keyboard’
LEDs 8 x Octave/Location
Input Patchbay 3.5 mm TS jack sockets
Timbre -8 V to +8 V, 50 kΩ impedance
Harmonics -5 V to +5 V, 100 kΩ impedance
FM -8 V to +8 V, 50 kΩ impedance
Morph -8 V to +8 V, 50 kΩ impedance
VCF In
VCF Cuto -5 V to +5 V
VCF Resonance -5 V to +5 V
Mix 1 and 2 -5 V to +5 V
VC Mix -5 V to +5 V
Osc Model -5 V to +5 V, 100 kΩ impedance
Osc V/octave -3 V to + 7 V
Osc Level 0 V to +8 V
Osc Trig +3.2 V minimum
Tempo -5 V to +5 V
