Behringer NEUTRON Quick Start Guides

User Con gurable Options & Features
Assignable Output
It is possible to select the source of the
“ASSIGN” output jack.
To change the source press & hold the
“OSC SYNC” button until both the “RANGE”
buttons are  ashing. The currently
selected assignable output is indicated
by the  ashing LFO shape LED - the
available options are (clockwise from the
sine shape):
1. OSC 1 CV
2. OSC 2 CV
3. “Note On” velocity
4. Modwheel
5. Aftertouch
Use the two range buttons to change
the selected output. When you’re done
press & hold the “OSC SYNC” button until
the “RANGE” buttons stop  ashing. The
currently selected assignable output
value will be stored & will persist across
power cycles.
OSC & LFO SHAPE MODE BLEND OR
SWITCHED
It is possible to either blend or switch the
OSC & LFO shape. This feature is incredibly
powerful unique sound creation tool.
For OSC1 press & hold “OSC1 RANGE”
button (this will enter the tuning feature).
The “PARAPHONIC” button will  ash if
shape mixing is disabled, or it will throb
if shape mixing is enabled. Press the
“PARAPHONIC” button to toggle the shape
mix state. Press & hold the “OSC1 RANGE”
to leave this mode.
Similarly, for OSC2 shape mixing press &
hold “OSC2 RANGE”; for LFO shape mixing
press & hold “LFO KEY SYNC”
TUNING
The Neutron will self-calibrate at start-up.
An additional “tune” feature is designed
to allow the user to manually tune the
oscillators to the last played midi note.
To tune OSC1 or OSC2 press & hold the
appropriate “RANGE” button until the
octave LED starts to  ash. Play a MIDI note.
The LFO shape LEDS will display the tuning
- turn the TUNE control until only the
descending saw LED is lit. To exit tuning
mode press & hold the RANGE button until
the octave LED stops  ashing.
Note tuning is not available when in
+/-10 Octave mode. (3 octave LEDs on).
ADVANCED FEATURES
Please refer to the Neutron user manual
available at musictri.be for more
detailed information.
Advanced Features Access Action Result Exit
Change Assignable
Output (ASSIGN)
Hold OSC SYNC Use RANGE
buttons to change
Output function
LFO shape displays
selected option.
Hold OSC SYNC
Envelope
Retriggering
Hold OSC SYNC the KEY TRK
button toggles the
retriggering mode
When the KEY
TRK LED is on -
retriggering is
enabled
Hold OSC SYNC
OSC 1 Shape
(Blend or Switched)
Hold OSC1 RANGE PARAPHONIC will
either throb or  ash.
Push to toggle mode
OSC 1 Shape
mode will toggle.
Blend or switch
Hold OSC 1 RANGE
OSC 2 Shape
(Blend or Switched)
Hold OSC2 RANGE PARAPHONIC will
either throb or  ash.
Push to toggle mode
OSC 2 Shape
mode will toggle.
Blend or switch
Hold OSC 2 RANGE
LFO
(Blend or Switched)
Hold LFO KEY SYNC PARAPHONIC will
either throb or  ash.
Push to toggle mode
LFO Shape mode
will toggle.
Blend or switch
Hold LFO KEY SYNC
OSC 1 Tuning Hold RANGE 1 LFO shape LEDs
shows tuning with
respect to the last
played MIDI note
Top center LFO
Shape LED indicates
that the oscillator is
in tune
Hold RANGE 1
OSC 2 Tuning Hold RANGE 2 LFO shape LEDs
shows tuning with
respect to the last
played MIDI note
Top center LFO
Shape LED indicates
that the oscillator is
in tune
Hold RANGE 2
Poly Chain mode Hold PARAPHONIC The LED will pulse
slowly in mono
mode - quickly in
duo mode
Poly-Chain mode
toggled on/o
Hold PARAPHONIC
(EN) Step 4: User Con gurable
Options & Features
40 41Quick Start GuideNEUTRON

Behringer NEUTRON Specifications

General

Product type	Analog synthesizer
Product color	Red
Sound effects	Overdrive
Volume control	Rotary
Built-in speaker(s)	No
Keyboard number of keys	0
Maximum polyphony (notes)	1
Power source type	DC
MIDI in	Yes
6.35 mm (1⁄4-inch) output	2
