WASP DELUXE Controls
Step 2: Controls
KEYBOARD Section
1. BEND knob shifts the keyboard pitch up (clockwise) or down (counterclockwise).
2. TUNE knob allows fine adjustment of the keyboard pitch.
3. GLIDE controls the rate of change from one note to the other. Turning the knob clockwise slows down the shift to the next pitch.
OSCILLATORS Section
4. FT knob for the upper oscillator sets the oscillator’s pitch.
5. WIDTH % knob controls the width of the oscillator’s sound.
6. WAVEFORM knob controls the shape of the waveform for the upper oscillator. In the OFF setting, the waveform is left as an unaltered sine wave.
The second-from-left setting imposes a “sawtooth” waveform, while the next set over creates a “square” waveform. The ENH setting acts as an enhancer to add punch, bit
and clarity to the oscillator’s tone.
