Behringer Xenyx 802 User Manual

10
XENYX 502/802/1002/1202
4. SPECIFICATIONS
Mono inputs
Microphone inputs (XENYX Mic Preamp)
Type XLR, electronically balanced,
discrete input circuit
Mic E.I.N. (20 Hz - 20 kHz)
@ 0 W source resistance -134 dB / 135.7 dB A-weighted
@ 50 W source resistance -131 dB / 133.3 dB A-weighted
@ 150 W source resistance -129 dB / 130.5 dB A-weighted
Frequency response <10 Hz - 150 kHz (-1 dB),
<10 Hz - 200 kHz (-3 dB)
Gain range +10 to +60 dB
Max. input level +12 dBu @ +10 dB gain
Impedance approx. 2.6 kW balanced
Signal-to-noise ratio 110 dB / 112 dB A-weighted
(0 dBu In @ +22 dB gain)
Distortion (THD+N) 0.005% / 0.004% A-weighted
Line input
Type 1/4" TRS connector
electronically balanced
Impedance approx. 20 kW balanced
10 kW unbalanced
Gain range -10 to +40 dB
Max. input level +22 dBu @ 0 dB Gain
Fade-out attenuation
1
(Crosstalk attenuation)
Main fader closed 90 dB
Channel muted 89.5 dB
Channel fader closed 89 dB
Frequency response
Microphone input to main out
<10 Hz - 90 kHz +0 dB / -1 dB
<10 Hz - 160 kHz +0 dB / -3 dB
Stereo inputs
Type 1/4" TRS connector,
electronically balanced
Impedance approx. 20 kW
Max. input level +22 dBu
EQ mono channels
L ow 80 Hz / ±15 dB
Mid 2.5 kHz / ±15 dB
High 12 kHz / ±15 dB
EQ stereo channels
L ow 80 Hz / ±15 dB
Mid 2.5 kHz / ±15 dB
High 12 kHz / ±15 dB
Aux sends
Type 1/4" TS connector, unbalanced
Impedance approx. 120 W
Max. output level +22 dBu
Stereo aux returns
Type 1/4" TRS connector,
electronically balanced
Impedance approx. 20 kW bal. / 10 kW unbal.
Max. input level +22 dBu
Main outputs
Type 1/4" TRS connector, unbalanced
Impedance approx. 120 W unbal.
Max. output level +22 dBu
Control room outputs
Type 1/4" TS connector, unbal.
Impedance approx. 120 W
Max. output level +22 dBu
Headphones output
Type 1/4" TRS connector, unbalanced
Max. output level +19 dBu / 150 W (+25 dBm)
Main mix system data
2
Noise
Main mix @ -oo,
Channel fader -oo -106 dB / -109 dB A-weighted
Main mix @ 0 dB,
Channel fader -oo -95 dB / -98 dB A-weighted
Main Mix @ 0 dB,
Channel fader @ 0 dB -84 dB / -87 dB A-weighted
Power supply
Power consumption 502: 13 W
802: 17 W
1002: 18 W
1202: 23 W
Mains voltage
USA/Canada 120 V~, 60 Hz, MXUL5 adapter
U.K./Australia 240 V~, 50 Hz, MXUK5 adapter
Europe 230 V~, 50 Hz, MXEU5 adapter
Japan 100 V~, 60 Hz, MXJP5 adapter
Dimensions
502
Dimensions (H x W x D) 1 5/6" / 1 1/2" (47 mm / 37 mm) x
5 1/4" (134 mm) x 7" (177 mm)
Weight (net) approx. 0.55 kg (1.21 lbs)
802
Dimensions (H x W x D) 1 5/6" / 1 1/2" (47 mm / 37mm) x
7 2/5" (189 mm) x 8 2/3" (220 mm)
Weight (net) approx. 1.00 kg (2.21 lbs)
1002
Dimensions (H x W x D) 1 5/6" / 1 1/2" (47 mm / 37 mm) x
7 2/5" (189 mm) x 8 2/3" (220 mm)
Weight (net) approx. 1.05 kg (2.31 lbs)
1202
Dimensions (H x W x D) 1 5/6" / 1 1/2" (47 mm / 37 mm) x
9 1/2" (242 mm) x 8 2/3" (220 mm)
Weight (net) approx. 1.35 kg (2.97 lbs)
Measuring conditions:
1: 1 kHz rel. to 0 dBu; 20 Hz - 20 kHz; line input; main output; unity gain.
2: 20 Hz - 20kHz; measured at main output. Channels 1 - 4 unity gain; EQ flat; all
channels on main mix; channels 1/3 as far left as possible, channels 2/4 as far
right as possible. Reference = +6 dBu.
BEHRINGER is constantly striving to manintain the highest professional standards. As a
result of these efforts, modifications may be made from time to time to existing products without
prior notice. Specifications and appearance may differ from those listed or illustrated.
4. SPECIFICATIONS

Behringer Xenyx 802 Specifications

General

Channels quantity	- channels
Digital sound processing	- bit
Total Harmonic Distortion (THD)	0.005 %
DJ mixer	-
Power consumption (typical)	13 W
Equalizer bands quantity	3

Weight and Dimensions

Depth	220 mm
Width	189 mm
Height	47 mm
Weight	1600 g
