XENYX X1204USB/1204USB
Specications
X1204USB 1204USB
Mono Inputs
Microphone Inputs (XENYX Mic Preamp)
Type
XLR connector, electronically balanced,
discrete input circuit
Mic E.I.N.1 (20 Hz - 20 kHz)
@ 0Ω source resistance -134 dB 135.7 dB A-weighted
@ 50Ω source resistance -131 dB 133.3 dB A-weighted
@ 150Ω source resistance -129 dB 130.5 dB A-weighted
Frequency response
(-1 dB)
<10 Hz - 150 kHz (-1 dB)
Frequency response
(-3 dB)
<10 Hz - 200 kHz (-3 dB)
Gain range +10 dB to +60 dB
Max. input level +12 dBu @ +10 dB GAIN
Impedance 2.6 k Ohms balanced
Signal-to-noise ratio 110 dB A-weighted (0 dBu In @ +22 dB GAIN)
Distortion (THD + N) 0.005% / 0.004% A-weighted
Line Input
Type ¼" TRS jack, electronicallybalanced
Impedance 20 k Ohms balanced, 10 k Ohms unbalanced
Gain range -10 dB to +40 dB
Max. input level 30 dBu
Frequency Response (Mic In - Main Out)
<10Hz - 90kHz +0 dB / -1 dB
<10Hz - 160kHz +0 dB / -3 dB
Stereo Inputs
Type 2 x ¼" TRS jack, balanced
Impedance 20 k Ohms balanced, 10 k Ohms unbalanced
Gain range -20 dB to +20 dB
Max. input level +22 dBu
CD/Tape In
Type RCA connector
Impedance 10 k Ohms
Max. input level +22 dBu
Equalizer
LOW 80 Hz / ±15 dB
MID 2.5 kHz / ±15 dB
HIGH 12 kHz / ±15 dB
AUX Sends
Type ¼" mono jack, unbalanced
Impedance 120 Ohms
Max. output level +22 dBu
X1204USB 1204USB
AUX Returns
Type ¼" TRS connector, balanced
Impedance 20 k Ohms balanced, 10 k Ohms unbalanced
Max. input level +22 dBu
Main Outputs
Type XLR, electronically balanced
Impedance 240 Ohms balanced, 120 Ohms balanced
Max. output level +28 dBu
Control Room Output
Type ¼" TS connector, unbalanced
Impedance 120 Ohms
Max. output level +22 dBu
Phones Output
Type ¼" TRS jack, unbalanced
Max. output level +19 dBu / 150 Ohms (+25 dBm)
CD/Tape Out
Type RCA connector
Impedance 1 k Ohms
Max. output level +22 dBu
DSP (X1204USB Only)
Converter
24-bit Delta-Sigma
64/128-times
oversampling
—
Sampling Rate 40 kHz —
Main Mix System Data (Noise)
Main mix @ -∞,
channel fader @ -∞
-105 dB / -108 dB Aweighted
Main mix @ 0dB,
channel fader @ -∞
-95 dB / -97 dB A weighted
Main mix @ 0dB,
channel fader @ 0dB
-82.5 dB / -85 dB Aweighted
Power Supply
Mains voltage 100 – 240 V~, 50/60 Hz
Power consumption 40 W
Fuse
(100 - 230V~, 50/60Hz)
T 1.6 A H 250 V
Mains connector Standard IEC receptacle
USB
Connecter Type B
Converter 16-bit
Sample Rate 48 kHz
Physical/Weight
Dimensions (H x W x D) 3.8 x 10.6 x 12.9" / 97 x 270 x 328 mm
Weight 8.4 lbs / 3.8 kgs

Behringer XENYX X1204USB Specifications

General

Type	Analog
Channels	12
Mic Preamps	4
Phantom Power	Yes
EQ Bands	3-band
Aux Sends	2
Headphone Output	1 x 1/4"
Tape Input/Output	Yes
Inputs - Other	4 XLR
Outputs - Main	2 x XLR, 2 x 1/4"
Outputs - Other	2 x 1/4" (Control Room)
Main Outputs	2 x XLR, 2 x 1/4" TRS
Inputs - Line	8 x 1/4"
