Behringer XENYX X1222USB User Manual

15 XENYX X1222USB User Manual
Channels 9/10, 11/12
Stereo line inputs
Type 2 x ¼" TRS connector, unbalanced
Impedance approx. 40 kΩ @ 0 dB Gain
Gain range -20 dB to +20 dB
Max. input level +22 dBu @ 0 dB Gain
CD/Tape In
Type RCA connectors
Impedance approx. 10 kΩ
Max. input level +22 dBu
EQ Mono Channels
Low 80 Hz / ±15 dB
Mid 2.5 kHz / ±15 dB
High 12 kHz / ±15 dB
Low cut 80 Hz, 18 dB/oct.
EQ Stereo Channels
Low 80 Hz / ±15 dB
Mid 2.5 kHz / ±15 dB
High 12 kHz / ±15 dB
MON/FX Send
Type ¼" TS connector, unbalanced
Impedance approx. 120 Ω
Max. output level +22 dBu
Aux Returns
Type ¼" TRS connector, unbalanced
Impedance approx. 10 kΩ
Max. input level +22 dBu
Main Outputs
Type XLR, electronically balanced
Impedance approx. 240 Ω balanced
approx. 120 Ω unbalanced
Max. output level +28 dBu
Headphone Output
Type ¼" TRS connector, unbalanced
Max. output level +19 dBu / 150 Ω (+25 dBm)
CD/Tape Out
Type RCA connectors
Impedance approx. 1 kΩ
Max. output level +22 dBu
DSP Texas Instruments
Converter 24-bit Sigma-Delta
64/128-times oversampling
Sampling rate 40 kHz
USB
Audio Stereo In/Out
Connector Type B
Converter 16-bit
Sample Rate 48 kHz
Main Mix System Data
Noise
Main mix @ -∞, -99 dB
Channel fader -∞ -101 dB A-weighted
Main mix @ 0 dB, -84 dB
Channel fader -∞ -87 dB A-weighted
Main mix @ 0 dB, -80 dB
Channel fader @ 0 dB -82 dB A-weighted
Power Supply
Mains Voltage 100 - 240 V~, 50 - 60 Hz
Power consumption 40 W
Fuse T 1.6 A H 250 V
Mains connection Standard IEC receptacle
Physical
Dimensions (H x W x D) approx. 3 / x 13 / x 13 /"
approx. 97 x 345 x 334 mm
Weight (net) approx. 8.38 lbs.
approx. 3.80 kg
Measuring conditions:
1: 1 kHz rel. to 0 dBu; 20 Hz - 20 kHz; line input; main output; unity gain.
2: 20 Hz - 20kHz; measured at main output. Channels 1 - 4 unity gain; EQ flat; all channels on main mix;
channels 1/3 as far left as possible, channels 2/4 as far right as possible. Reference = +6 dBu.
BEHRINGER is constantly striving to manintain the highest professional standards. As a result of these efforts,
modifications may be made from time to time to existing products without prior notice. Specifications and
appearance may differ from those listed or illustrated.

Behringer XENYX X1222USB Specifications

General

Type	Analog
Channels	16
Phantom Power	Yes
Inputs - Line	8
Faders	60mm
USB	Yes
Tape Input/Output	Yes
Mic Preamps	4 XENYX Mic Preamps
EQ	3-band
Effects	Yes
Aux Sends	2
Headphone Output	1/4" TRS
