Behringer XENYX X1222USB User Manual

2 XENYX X1222USB User Manual
Thank you
Congratulations! In purchasing the BEHRINGER XENYX you have acquired a
mixer whose small size belies its incredible versatility and audio performance.
The XENYX Series represents a milestone in the development of mixing console
technology. With the new XENYX microphone preamps including phantom power
as an option, balanced line inputs and a powerful eects section, themixing
consoles in the XENYX Series are optimally equipped for live and studio
applications. Owing to state-of-the-art circuitry, your XENYX console produces
a warm analog sound that is unrivalled. With the addition of the latest digital
technology, these best-in-class consoles combine the advantages of both analog
and digital technology.
Table of Contents
Thank you .......................................................................2
Important Safety Instructions ...................................... 3
Legal Disclaimer ............................................................. 3
Limited Warranty ........................................................... 3
1. Introduction ............................................................... 5
1.1 General mixing console functions ............................... 5
1.2 The user’s manual ............................................................... 6
1.3 Before you get started ...................................................... 6
2. Control Elements and Connectors .......................... 6
2.1 Mono channels .................................................................... 6
2.2 Stereo channels ................................................................... 8
2.3 Connector panel and main section ............................. 8
2.4 Graphic 7-band equalizer .............................................. 11
2.5 Rear view of X1222USB ................................................... 12
3. Digital Eects Processor and
XPQ Surround Function ............................................... 12
3.1 Digital eects processor ................................................. 12
3.2 XPQ surround function .................................................. 13
4. Installation ............................................................... 13
4.1 Rack mounting ................................................................... 13
4.2 Cable connections ........................................................... 13
5. Specications ........................................................... 14

Behringer XENYX X1222USB Specifications

General

Type	Analog
Channels	16
Phantom Power	Yes
Inputs - Line	8
Faders	60mm
USB	Yes
Tape Input/Output	Yes
Mic Preamps	4 XENYX Mic Preamps
EQ	3-band
Effects	Yes
Aux Sends	2
Headphone Output	1/4" TRS
