Specifications
General
Frequency range
UHF:400‐480MHz
Channel Capacity 32
Zones 2
Channel Spacing
12.5KHz
Operating Voltage DC7.4V (±20%)
Battery Capacity 1800 mAh
Battery Life（5/5/90）
Digital 18 Hours
Frequency Stability ±1.5ppm
Antenna Impedance 50Ω
Dimensions (L×W×H) 59.7（L）*35(W)*114(H)mm
Weight 264g(Including Battery)
Transmitter
RF Output Power
High：5W；
Low：1W；
4FSK Modulation 12.5kHz Only data：7K60FXD
12.5kHz data and audio：7K60FXE
Conducted Emission -36 dBm≤1GHz/-30 dBm≥1GHz
Adjacent Channel Power ≤-60dB
Digital Voice coder Type AMBE3000
Receiver
Digital Sensitivity 5% BER：0.25 uV
Intermodulation 65dB
Adjacent Channel Selectivity 60 dB
Spurious Response Rejection 70 dB
