Belimo CMU Series User Manual

20
V4. 12. 2010
.
Subject to modification
SMU230(-S/-F)
Technical data
Electrical data
AC 100...240V 50/60Hz
AC 85...265V
2.5W @ running / 0.6W @ holding
6VA
Cable 1m, 3x0.75mm
2
Functional data
20Nm
Selectable by switch
Max. 95
°
, adjustable by mechanical stops
150s for 95
°
Max. 48dB(A)
Mechanical, remote visible
Working conditions
IP54 in any direction
CE according to 89/336/EEC
Type 1 to EN 60730-1
-30...+50
°
C
-40...+80
°
C
95% RH, non-condensing (EN 60730-1)
Maintenance-free
Dimensions / weight
See ‘Dimensions’
12x12mm
Min. 42mm (20mm for reverse mounting)
10...20mm
Approximately 1050g
Dimensions [mm]
Cable 1m, 3x0.75mm
2
139
65
46
30
109
41
8
8
1 SPDT, 1mA...3(0.5)A, AC 250V , adjustable
II (totally insulated)
CE according to 73/23/EEC
SMU230-F SMU230(-S)
109
30
97
23
4.2
8.8
57
Gearing latch disengaged by pushbutton, self-resetting
(10...26.7mm with K-ENSA - optional)
Nominal voltage
Nominal voltage range
Power consumption
Wire/transformer sizing
Auxiliary switch
SMU230-S
Connection : Motor
Auxiliary switch SMU230-S
Torque
Direction of rotation
Manual override
Angle of rotation
Running time
Sound power level
Position indication
Protection class
Degree of protection
EMC
Low voltage directive
Ambient temperature
Mode of operation
Maintenance
Non-operation temperature
Humidity test
Shaft length
Dimensions (LxWxH)
SMU230-F
Weight
Shaft: SMU230(-S)
•ΓFor operation of air control dampers in HVAC system
•ΓTorque: 20Nm
•ΓNominal voltage: AC 100...240V
•ΓControl: Open/Close or 3-point
