V4. 12. 2010
.
Subject to modification
21
SMU230-SR
Technical data
Electrical data Nominal voltage
Nominal voltage range
Power consumption
Wire/transformer sizing
Connection cable: Power supply
Cable 1m, 4x0.75mm
2
Functional data
Torque20Nm
Control signal
Position accuracy
Direction of rotation
Angle of rotation
Running time
Sound power level
Position indication
Working conditions
Protection class
II (totally insulated)
Degree of protection
EMC
Mode of operation
Ambient temperature
Non-operation temperature
Humidity test
Maintenance
Dimensions / weight
Dimensions (LxWxH)
Shaft length
Shaft
10...20mm
Weight
Approximately 1200g
Signals
Low voltage directive
Dimensions [mm]
139
65
46
30
131
41
88
Gearing latch disengaged by pushbutton, self-resetting
Manual override
(10...26.7mm with K-ENSA - optional)
•ΓFor operation of air control dampers in HVAC system
•ΓTorque: 20Nm
•ΓNominal voltage: AC 100...240V
•ΓControl signal: DC 2(0)...10V
•ΓPosition feedback: DC 2...10V
Feedback signal
AC 100...240V 50/60Hz
AC 85...265V
3.5W @ running / 1W @ holding
6.5VA
Cable 1m, 2x0.75mm
2
20Nm
DC 2(0)...10V (input impedance 100k
Ω
)
±5%
Selectable by switch
Max. 95
°
, adjustable by mechanical stops
150s for 95
°
Max. 48dB(A)
Mechanical, remote visible
IP54 in any direction
CE according to 89/336/EEC
Type 1 to EN 60730-1
-30...+50
°
C
-40...+80
°
C
95% RH, non-condensing (EN 60730-1)
Maintenance-free
202x88x64mm
Min. 42mm (20mm for reverse mounting)
CE according to 73/23/EEC
DC 2...10V
