V4. 12. 2010
.
Subject to modification
23
GMU24-SR
Technical data
Electrical data
Nominal voltage
Nominal voltage range
Power consumption
4.5W @ running / 2W @ holding
Wire/transformer sizing
Connection cable
Functional data
Torque
Control signal
Feedback signal
Position accuracy
Direction of rotation
Angle of rotation
Running time
Sound power level
Position indication
Working conditions
Protection class
Degree of protection
EMC
Mode of operation
Ambient temperature
Non-operation temperature
Humidity test
Maintenance
Dimensions / weight
Dimensions (LxWxH)
Shaft length
Shaft
12...26.7mm/12...25.2mm
Weight
Dimensions [mm]
Gearing latch disengaged by pushbutton, self-resetting
Manual override
AC 24V 50/60Hz, DC 24V
AC/DC 19.2...28.8V
6.5VA
Cable 1m, 4x0.75mm
2
40Nm
DC 2(0)...10V (input impedance 100k
Ω
)
DC 2...10V
±5%
Selectable by switch
Max. 95
°
, adjustable by mechanical stops
150s for 95
°
Max. 48dB(A)
Mechanical, remote visible
III (safety low voltage)
IP54 in any direction
CE according to 89/336/EEC
Type 1 to EN 60730-1
-30...+50
°
C
-40...+80
°
C
95% RH, non-condensing (EN 60730-1)
Maintenance-free
220x116x70mm
Min. 52mm (20mm for reverse mounting)
Approximately 1700g
•ΓFor operation of air control dampers in HVAC system
•ΓTorque: 40Nm
•ΓNominal voltage: AC/DC 24V
•ΓControl signal: DC 2(0)...10V
•ΓPosition feedback: DC 2...10V
60116
70
179
14336 41
Standard :
Length
>52
>20
12...26.7
>12
>12
12...26.7 <25
<25
Damper spindle
12...22mm 12...18mm
22...26.7mm 12...18mm
