Siemens
Make & Model
Power
Belimo Replacement
GGD121
24
FSAF24
FSNF24
GGD221
120
FSAF120
FSNF120
GGD321
230
FSAF230
FSNF230
GND12x.1x
24V
FSLF24
GND22x.1x
120V
FSLF120
GND32x.1x
230V
FSLF230
Electronic Fuse Link (24 Vac)
ASK79.165 165°F (74°C)
BAE165 US
ASK79.212 212°F (100°F)
None. Call if needed.
ASK79.250 250°F (121°C)
None. Call if needed.
ASK79.350 350°F (177°C)
None. Call if needed.
Optional
Two Auxiliary Switches Fixed 5° and 85°
Fire & Smoke Damper Technical Details
A number of different brackets have been used. All allow mounting of Belimo.
WARNING!
Read Data Sheet provided in box with each actuator for specific wiring details.
Small bracket
Large bracket
Air Balance Honeywell ML&MS Types to Belimo FSxx March 2018
8
