• Height to bottom of TV
Fig. 3-2
3-2. MEASURE the distance from the mounting holes on the back of your television to the top and bottom edges of the television to
determine the true center of the television once it will be mounted. Many television manufacturers do not place the mounting holes
exactly centered in the television.
3-3. MEASURE from the floor up, and make small marks on the wall to help you determine the desired TV height. Using a level, LINE UP
the Installation Template with your pencil markings and TAPE it into place. [FIGURE 3-2]
