MOUNTING TO SOLID CONCRETE OR CINDER BLOCK:
3-4. Carefully DRILL four holes using a 5/16" (or 8mm) masonry drill bit in the “A”, “B”, “C”, and “D” locations noted on the Installation
Template. NOTE: EACH HOLE SHOULD BE AT LEAST 3" (76 MM) DEEP. [FIGURE 3-4]
IMPORTANT: DO NOT DRILL INTO MORTAR JOINTS! DRILL HOLES AT LEAST 1" (25.4 MM) FROM THE JOINTS.
3"
(76 mm)
Fig. 3-4
A
C
B
D
USE LINES ON INSTALLATION TEMPLATE TO ALIGN TEMPLATE WITH STUD PENCIL MARkINGS.
