Bell'O TPC2133 - Page 6

Fig. 1-2
M1
1-2. LOCK the Frame Assembly (M1) into an open position by engaging the Locking Mechanisms as shown.
NOTE: IF YOU WILL BE USING THE TPC2133 WITH THE TV MOUNTING SYSTEM (OPTION 2), CONTINUE FOR FURTHER
INSTRUCTIONS. IF YOU WILL BE USING THE WALL MOUNT FEATURE (OPTION 3), PLEASE SKIP TO PAGE 14.
