bell issimo 2-72 Way Video Entry System
PD-098 Issue 4B Installation and Operating Manual Page 13 of 44
Cable Distances – Colour Videophones
Video Controller to Videophone
System
Distance
Cable
Comments
Single videophone per
output
< 150m
1 x Cat5
> 300m
1 x Cat5
2 x 1mm
2
Single videophone + 3
extensions on each
output, all cable powered
< 50m
1 x Cat5
Only Master videophone has
‘Auto display’;
extensions are daisy-chained
< 200m
1 x Cat5
2 x 1mm
2
Single videophone per
output with separately
powered extensions
< 150m
1 x Cat5
150m maximum to the cable
powered videophone;
daisy-chain up to 300m total.
> 300m
1 x Cat5
2 x 1mm
2
All videophones locally
powered with a 340C
power supply
< 300m
1 x Cat5
Locally powered videophones
have ‘Auto display’;
extensions are daisy-chained
<25m to 340C
1 x pair of
Cat5
<100m to 340C
2 x 1mm
2
Door Controller to Video Controller(s)
System
Distance
Cable
Comments
All Systems
<200m
1 x Cat5
N.B. maximum length from any camera to any
videophone to be less than 300m
Panel to Door Controller
System
Distance
Cable
Comments
All Systems, each entrance
<50m
1⅛ x Cat5
+⅛ per button
See page 28 for detail
Lock Release up to 1A
<10m
¼ x Cat5
<50m
2 x 1mm
2
Option: Exit button
<50m
¼ x Cat5
Option: Trades button
<50m
¼ x Cat5
Requires a Time-clock
Option: Door Monitor Switch
<50m
¼ x Cat5
Power Supply to Controller
System
Distance
Cable
Comments
All Systems, each PS4 to
BSD8 or BSD72 or BSC4
<3m
2 x 1mm
2
Total length of any daisy chain
<5m
2 x 1.5mm
2
NB. A Cat5 cable has 4-pairs (8 cores)
For larger cable distances please contact manufacturer.
