bell issimo 2-72 Way Video Entry System
PD-098 Issue 4B Installation and Operating Manual Page 9 of 44
Design Considerations
Equipment List
A BS-n bellissimo Video Kit (where n is the no of ways) comprises the following: -
Model No
Description
N x BS
Videophone (N is the no of phones)
1 x BSPn
Standard panel with a speech unit and camera.
1 x BSD8 or BSD72
Door controller (BSD72 required for > 8 ways)
M x BSC4
Video controller (one required for every 4 ways = N/4 rounded up)
K x PS4
4A 12V power supply. (one required for every 8 to 16 ways)
1 x 203
Fail-secure lock release
E.g. A BS6 Six way bellissimo Video Kit comprises the following: -
Model No
Description
6 x BS
Videophone
1 x BSP6
Standard SPA panel with a speech unit and camera
1 x BSD8
Door controller
2 x BSC4
Video controller
1 x PS4
4A 12V power supply
1 x 203
Fail-secure lock release
E.g. A BS22 Twenty two way bellissimo Video Kit comprises the following: -
Model No
Description
22 x BS
Videophone
1 x BSP22/VR
Vandal resistant panel with a speech unit and camera
1 x BSD72
Door controller
6 x BSC4
Video controller
2 x PS4
4A 12V power supply
1 x 203
Fail-secure lock release
For a bellini style kit order as BLV2 through BLV8. N.B. bellini systems do not include a
203 lock release.
Options
The following options are available: -
● Extensions model BS videophone(s).
● Audio only phones model BSA as extensions.
● Additional entrances, each comprising a BSD8 or BSD72 controller and BSPn
panel. (See also power supply requirements).
● Alternate lock releases, fail-safe and fail-secure.
● Timed Trades facility; specify TRBS to add another button and a TS2000-BST time-
clock. On vandal resistant panels the extra button will be engraved “TRADES”
● Exit button. Model 5077 surface and model 5078 flush versions are available.
● Battery back-up power supply, Model 840 (12V 4A).
● DDA panels (Contact sales for further information).
● Vandal Resistant Panels (standard above 8 ways)
