Bell System bellview - 819 S DIP Switch Settings

Bell View Video Entry System
17
Adjustments on 2 door systems (819S DIP Switch Settings)
The DIP switch is located on the lower PCB and marked ‘SW2'.
off - DIP Switch down
on - DIP Switch up
* - Default setting
Setting
DIP Switch Position
1 2 3 4 5 6 7 8
Lock Release Time
3 sec off off
off - Switch down
on - Switch up
* 5 sec on off
10 sec off on
20 sec on on
Call / Active Time
3 4
30 off off
* 60 on off
90 off on
120 on on
Mode Setting
8
Normal off
For the system to operate correctly the Mode Setting MUST be set as above.
