Bell View Video Entry System
24
Model BV Video Telephone
Size 180 mm x 245 mm x 75 mm
Fixing Wall mounted
Supply Voltage 10 V DC min.
15 V DC max.
Current consumption 405 mA maximum active
27 mA maximum idle
Call / Active time 30, 60, 90 or 120 seconds
Buzzer mute time 1 minute min
10 hours max
Model 61 Speech Unit
Size 98 mm x 60 mm x 24 mm
Supply voltage 6 V AC/DC min.
15 V AC/DC max.
Current consumption 100 mA DC max.
140 mA AC max.
Model BV700 Camera
Size 60 mm x 57 mm x 31 mm
Image Device 1/3" CCD
Sensitivity 0.1 lux.
Current consumption 175 mA max. without IR
215 mA max. with IR
Minimum focus 100 mm
Viewing angle 92E (typical)
Supply Voltage 9 V DC minimum
15 V DC maximum
