Bell System bellview - Model 440 Power Supply; Model 540 Power Supply

Bell View Video Entry System
25
Model 440 Power Supply
Size 236 mm x 105 mm x 81 mm
Output Voltage (regulated) 12.0 V DC min.
13.8 V DC nom.
15.0 V DC max.
Output Current 1.5 A continuous
2.0 A peak (5 minutes max.)
Short Circuit Duration Infinite
Mains Supply Internal fuse T250mA Anti-surge
Supply Voltage 240 V 50 Hz nominal
Temperature Range 0EC to 50EC
Model 540 Power Supply
Size 236mm x 105mm x 81mm
Output Voltage (regulated) 12.0 V DC min.
13.8 V DC nom.
15.0 V DC max.
Output Current 1.5 A continuous
2.0 A peak (5 minutes max.)
Lock outputs 12 V DC @ 0.5 A max. resistive or inductive
Lock Time 3 seconds min.
27 seconds max.
Mains Supply Internal fuse T250mA Anti-surge
Supply Voltage 240 V 50 Hz nominal
Temperature Range 0EC to 50EC
