Bell Console 300 User Manual

Fine Tune
Magnet/Sensor
Positioning
STEP 5
2mm
MAX
Adjust the sensor & magnet location so that:
A) The magnet passes by the edge of the sensor
marked with the arrow when the wheel rotates
B) There is no more than
1
⁄8
"
(3 mm) clearance
between the sensor and the magnet
Now lift & spin the front tire. The computer display
will change with the spinning tire, if the sensor
and magnet are installed correctly. If the computer
display remains constant, further adjustment of the
sensor and magnet location is necessary.
(
3 mm
)
1
⁄8
"
MAX
