Bell Console 500 User Manual

Front Wheel
Sensor
Installation
STEP 3
S
E
N
S
O
R
2
3
3V
CR2032
Clamp the magnet onto the spoke of front wheel and attach
the transmitter to the right fork (right side when you stand in
front of bicycle) by using the cable ties as shown in Fig. 2.
The silver arrow on the transmitter must face towards the
wheel.
Make sure the arc of magnet intersects the alignment arrow on
the transmitter with 2 mm clearance as shown in Fig. 3.
G G
E
C
C
H
E
E
I
I
2mm Max

Bell Console 500 Specifications

General

Brand	Bell
Model	Console 500
Category	Bicycle Accessories
Language	English
