Belling BRD900DF - Fitting burner caps and heads; Pan placement

USING YOUR APPLIANCE
Fitting burner caps and heads
angled
parallel
burner cap
burner head
burner cap not central
Pan placement
Always make sure that your pans are placed centrally and do not allow the ame to extend over the
base of the pan. Do not place pans directly onto the burners.
Pan sizes required
Dual Fuel
Hob Cook Zones Minimum Pan Sizes (mm) Maximum Pan Sizes (mm)
Rapid & Wok
100
260
All other cook zones 250
