Belling ELECTRIC RANGE - CONNECTING THE ELECTRICITY SUPPLY; TERMINAL BLOCK WIRING

INSTALLATION INSTRUCTIONS RANGE ELECTRIC
CONNECTING THE ELECTRICITY
SUPPLY - TERMINAL BLOCK
• Thisappliancemustbettedtoa
switch providing all pole disconnec-
tion with a minimum contact separa-
tion of 3mm
• Access to the mains terminal is
gained by removing the terminal
block cover at the rear of the appli-
ance.
• Connection should be made with a
suitableexiblecable.
• First strip the wires then push the
cable through the cable clamp.
• Connect the cable to the terminal
block and tighten the cable clamp
screws - see diagram.
• Rettheterminalboxcover.
• Sufcientcableshouldbeusedto
allow the cooker to be pulled out,
butmusthangclearoftheoorsoit
does not become twisted or trapped
when the cooker is pushed back.
Please ensure that the user has this copy
of the handbook, and the appliance is in
place. Thank you.place. Thank you.
