D) GAS TAPS
FOLLOW STEP 8 (PAGE 9) LIFT HOB
TOP
FOLLOW STEP 6 (PAGE 7) REMOVE
FACIA PANEL
REMOVE 1 SCREW AS SHOWN ON
EITHER SIDE
PULL FORWARD INNER FACIA PANEL
T O GAIN ACCESS TO THE 2 TAP
SECURING SCREWS
UNDO BUNDY TUBE CONNECTION
AND REMOVE
DISCONNECT THERMOCOUPLE
REMOVE 2 GAS TAP SECURING
SCREWS AND REMOVE THE TAP
WHEN REPLACING TAP ALWAYS
ENSURE THAT A NEW TAP WASHER IS
FITTED (part number 081423974)
