H) DOOR SEAL
THE DOOR SEAL IS REMOVED BY
JUST PULLING IT IS SECURED IN THE
GAP BETWEEN THE CAVITY AND
FRONFRAME AND REQUIRES NO
OTHER FIXING
T O REFIT PUSH IN ALWAYS ENSURE
THAT DOOR SEAL LIP IS FACING COR-
RECT WAY
I) GRILL ELEMENT
FOLLOW STEP 7 (PAGE ?) REMOVE
REAR SERVICE PANEL
DISCONNECT WIRES
REMOVE GRILL ELEMENT GUARD BY
LOOSENING 2 HIDDEN SCREWS
(POSITIONS INDICATED ) AND
SLIDING OFF
REMOVE 2 SECURING SCREWS FROM
ELEMENT BRACKET AND REMOVE
FROM CAVITY BY PULLING
FORWARD
