J) TOP OVEN BURNER
LOOSEN HIDDEN SCREW IN BURNER
SHIELD( AS INDICATED ) AND SLIDE
AWAY
TO REMOVE THE BURNER REMOVE
THE SECURING NUT IN THE MIDDLE
OF THE BURNER
PULL THE BURNER FROM THE
BURNER HOUSING
THE ELCTRODE CAN NOW BE
REMOVED FROM THE BURNER
WITH THE BURNER SHIELD RE-
MOVED THE THERMOCOUPLE CAN
BE REMOVED BY UNDOING THE
SECURING NUT AND PULLING THE
T/COUPLE FROM IT’S HOLDER
