Belling IH60 - Page 16

INSTALLATION INSTRUCTIONS - INDUCTION
Clearances and dimensions – requirements
No shelf or overhang of combustible
material should be closer than 650mm
above the hob.
There must be a minimum clearance of
50mm between the edges of the hob
and any side walls; this clearance must
be maintained up to 420mm above the
worktop.
There must be a minimum clearance of
50mm between the rear edge of the hob
and the rear wall. This clearance must
be maintained up to 650mm above the
worktop.
When installing an extractor hood above
the hob, refer to their Manufacturer’s
instructions.
Clearan ces and dimensions – requirements
No shelf or overha ng of combustible ma terial should be closer than 650mm above the hob.
There must be a minimum clearance of 50mm between the edges of the hob an d any side
walls; this clear ance must be maintained up to 420mmabove the worktop.
There must be a minimum clearance of 50mm between the rear edge of the hob an d the re ar
wall. This clearance must be maintained up to 650mm abov e the worktop.
When installing an extractor hood above the hob, re fer to their Manufacturer’s instructions.
