Know Your Control Panel
Control Knobs & Switches The hob (Gas hotplates) control knobs can only be rotated anti-clockwise
from the off position.
The ovens thermostat control knobs can only be rotated clockwise from the
off position.
The multifunction selector switch knob can be rotated in either direction from
the off position.
The spark ignition switch is operated as follows.
Depress and hold in the push-button. This will provide a repetitive spark to
the burners.
(5) Gas Hotplate Controls
Main Oven Neon
Multifunction Selector
(Programmable Timing Option)
Large Elec Multifunction Oven Thermostat
Switch (Main Oven)
200
230
150
100
70
200
230
m
100
150
and Large Elec Oven Timer
Electronic Digital Clock, Minute Minder
Spark Ignition Switch
stop
Small Oven Neon
Small Conventional Elec Oven Thermostat
