6 Specifications
MODEL SB9015F 15” i3 All-in-one Touch POS Terminal
Main Board
CPU Intel i3-2310E Processor dual core 2.1GHz
System Chipset HM65
Memory 2 slots, DDR3 1066/1333, up to 4GB
Storage SATA 2.5 inch Hard Disk Drive, 320GB or higher
Display
LCD panel 15” TFT LCD
Resolution 1024x768
Brightness 250cd/m
2
Touch Screen 5-wire resistive touch (RS232 interface)
Tilting Angle 0 to 90°
I/O Ports
External DC Input 1x DC jack (connected to power adapter)
PS/2 Port 1x PS/2 keyboard
Serial Ports 3x DB9 with DC5V/12V on pin 9 (jumper option),
1x RJ45
Parallel Port Optional 1x DB25 on cable
VGA 1x DB15 2
nd
video VGA connector
LAN 1x RJ45, 10/100M/1Gbit
USB 6x USB 2.0
Cash Drawer Port 1x RJ11, 12V/24V jumper selectable
Audio 1x audio out, 2x 1W built-in speaker
DC Output 1x DC 12V output
Environment
Operating Temperature 0°C to 40°C
Storage Temperature -25°C to 70°C
Relative Humidity 8% to 80% non-condensing
Electrical (External Power Adapter)
Input 100V to 240VAC, 50 to 60Hz, 2.0A
Output DC 24V 5A
Output Power 120W max
Mechanical
Dimensions 329x348x213mm
Weight 10Kg
