Benchmark Games Ticket Station - Installing a Card Swipe

If Installing a card swipe:
Locate the Ticket Station Main Controller Board on the door.
1. Speaker
2. Programming buttons
3. SD Card Holder
4. Inputs/Power(P5)
5. Output/Signals(p11)
6. RS485
Find your Card Swipe Conversion harness as shown on the right.
This will connect you card swipe system into our board.
1
2
3
4
5
6
