14
NOTE: CHECK THE TIGHTNESS OF THE BLADE SECURING BOLT BEFORE,
DURING AND AFTER EACH USE.
Release the tension on blade guard and remove the piece of wood or screwdriver
that is holding it in the open position. Slowly release the guard so that it covers
the blade. Check the operation of the blade guard making sure that it operates
correctly.
REMOVING THE BLADE
CAUTION: Remove the battery pack from the saw.
1. Depress the spindle lock button and remove the blade screw by turning
it clockwise.
2. Remove the outer blade washer.
3. Remove the blade.
ATTACHING THE EDGE GUIDE
CAUTION: Before attaching the edge guide, please ensure the battery is
removed from the saw.
1. Place the edge guide through the holes in the base Fig.6.
2. Adjust the edge guide to the width needed and then tighten the parallel guide
locking knob making sure the guide is secure.
FIG. 6
NOTE: USE THE EDGE GUIDE PROVIDED WHEN MAKING LONG OR WIDE
RIP CUTS WITH THE SAW.
20V BRUSHLESS 7-1/4" CIRCULAR SAW
1265-002
