PARTS LIST
KEY #
PART # PART NAME / QUANTITY
KEY # PART # PART NAME
1
4020080063 Screw M6x13+ Washer
Ø18.5 / 1
2
2030030246 Blade Washer / 1
3
6070030004 Blade / 1
4
4100020039 Circlip 32 / 1
5
4020010031 Screw M3x10 / 1
6
3120100054 Lever for Guard / 1
7
2020080053 Removable Guard / 1
8
2050060272 Spring / 1
9
4020010053 Screw M4x14 / 1
10
4040010044 Washer Ø4xØ8x1.5 / 1
11
3140090026 Rubber Block / 1
12
1220030013 Laser Head / 1
13
4030010259 Screw Pwa 3x7 / 2
14
3160060102 Laser Seat / 1
15
1220040029 Laser / 1
16
4020020010 Screw M 4x10 / 1
17
4030010099 Screw St 3.9x14 / 1
18
3160090125 Laser Cover
/ 1
19
1062020072 Laser Switch / 1
20
1130030085 Laser Pcb / 1
21
3160090126 Laser Box / 1
22
2020080052 Fixed Guard / 1
23
3160090127 Cover / 1
24
4020010217 Screw M4x7 / 4
25
3110010263 Laser Decorative Plate / 1
26
2030100093 Hook / 1
27
2030020403 Hook Washer / 1
28
2050060283 Spring / 1
29
4020010218 Screw M 4x11 / 2
30
3150160293 Hook Fixing Seat / 1
31
4130010015 Pin / 1
32
2050060282 Spring / 1
33
2030250023 Spindle Lock Lever / 1
34
3140070037 Rubber Cover / 1
35 3160010079
Motor Barrel / 1
36 3150050107
Ring / 1
37 4030010229
Screw St 3.9x42 / 2
38 4030010096
Screw St 3.9x12 / 8
39 3010070027
Housing / 1
40 4010010034
Bearing 607-2z / 1
41 1030300009
Motor Assembly / 1
42 1060190008
Switch / 1
43 3120040063
Switch Lock Lever / 1
44 2050060218
Switch Spring / 1
45 3120010101
Switch Button / 1
46 4010010038
Bearing 609-2z / 1
47 4010010032
Bearing 606-2z / 1
48 2040080063
Big Gear / 1
49 2040310065
Shaft Coat / 1
50 40100
10045
Bearing 6001-2z / 1
51 2040050187
Shaft / 1
52 2020130044
Bearing Seat / 1
53 2020150084
Nut / 1
54 4020010115
Screw M4x28 / 4
55 2030030323
Lever for Depth / 2
56 4100050004
Ring / 2
57 2040150036
Nut / 2
58 2030020116
Washer Ø6xø13x2 / 2
59 2020120049
Aluminum Plate / 1
60 4050040023
Bolt L25 / 1
61 2050060228
Spring / 1
62 1180050051
Ruler Knob / 1
63 3110040015
Angle Guide / 1
64 2030270017
Casing / 1
65 4020010117
Screw M 4x37 / 1
To Next Page
