34
10. TECHNICAL SPECIFICATIONS
SPECIFICATIONS PARAMETERS
ENGINE
Type 4-stroke, overhead valve,
single cylinders, forced-air cooling
Engine Displacement 212cc
Engine Speed 3600 rpm
Spark Plug F7RTC
Spark Plug Gap 0.024 - 0.032 in. (0.6-0.8mm)
Valve Intake Clearance 0.0031 - 0.0047 in. (0.08-0.12mm)
Valve Exhaust Clearance 0.0051 - 0.0067 in (0.13 - 0.17mm)
Start System Recoil Start
Fuel Type Unleaded Gasoline
Oil Capacity 20 . oz. / 600mL
Oil Type SAE 10W-30
GENERATOR
Model Name BG4000i
Rated Frequency 60Hz
Rated Voltage 120V
Rated Current 26.7A
Rated Output Power 3,200W
Max. Output Power 4,000W
OTHER
SPECIFICATIONS
DC Output 12V/8A
Fuel Tank Volume 1.8 Gal / 7L
Run Time (100% load) 3.6h @ 3200W
Working Ambient Temperature 5°F to 104°F (-15°C to 40°C)
Max. Altitude (Unmodied) 3280 ft. / 1000m
Sound Power Level at 7m 73-81dB(A)
Dimensions (L*W*H) 19.1” x 14” x 18.3”
Net Weight 62.8 lbs / 28.5kg
Noise level is measured when EcoMode is ON and may vary in different environments.
BG i-SERIES
