Parts List
87-ASM-24
Ticket Taker
87-ASM-25
Ticket Taker
Top
87-ASM-26
Ticket Taker Belt
Assy.
87-ASM-27
Ticket Taker
Body
87-ASM-28
Ticket Cutter
87-ASM-45
Ticket Taker
Stepper Motor
87-ASM-46
Solenoid
Valve Assy.
PCB-020
Opto Transmitter
Single
PCB-021
Opto Receiver
Single
PCB-022
Barcode
Reader
PCB-026
Hall Effect
Sensor
PCB-027
Printer
Driver
Board
