Benchmark Ticket Station - Page 8

8
2. Ticket taker top assembly includes:
a. Upper urethane roller1
b. Ticket sense opto receiver2
c. Notch sense opto receiver
3
d. Upper barcode scanner
4
e. Blue flat springs5
3. Ticket taker belt assembly includes:
a. Ticket transport belts
1
b. Lower barcode scanner2
c. Notch opto transmitter3
4. Ticket taker cutter assembly
5. Drive motor assembly includes:
a. Stepper motor1
b. Hall effect sensor2
