Other
Operating mode ......................................................continuous operation
Mounting .............................................................................. any position
Degree of protection, internal components (DIN EN 60529) ..............IP30
Degree of protection, terminals (DIN EN 60529) ................................IP20
Enclosure material ............................................................ polycarbonate
Flammability class .................................................................... UL94 V-0
DIN rail mounting acc. to ......................................................... IEC 60715
Screw mounting............................................. 2 x M4 with mounting clip
Weight ........................................................................................≤ 150 g
( )* = factory setting
Ordering details
Standards
The ISOMETER® IR420 series complies with the require-
ments of the following device standards:
• DIN EN 61557-8 (VDE 0413-8)
• EN 61557-8
• IEC 61557-8
Sonstiges
Betriebsart ..........................................................................Dauerbetrieb
Einbaulage ................................................................................... beliebig
Schutzart, Einbauten (DIN EN 60529) ................................................IP30
Schutzart, Klemmen (DIN EN 60529) .................................................IP20
Gehäusematerial ..................................................................Polycarbonat
Entflammbarkeitsklasse ........................................................... UL94 V-0
Schnellbefestigung auf Hutprofilschiene .................................. IEC 60715
Schraubbefestigung ............................................2 x M4 mit Montageclip
Gewicht ........................................................................................≤ 150 g
( )* = Werkseinstellung
Bestelldaten
Typ Versorgungsspannung (U
s
)
absolut
/ Supply voltage (U
s
)
absolute
Klemme / Terminal Art.-Nr. / Art. No.
IR420-D4-1
DC 9,6…94 V / AC 16…72 V, 42…460 Hz
Schraubklemme
Screw type terminal
B71016409
IR420-D4-1
Federklemme
Push-wire terminal
B91016409
IR420-D4-2
DC 70…300 V / AC 70…300 V, 42…460 Hz
Schraubklemme
Screw type terminal
B71016405
IR420-D4-2
Federklemme
Push-wire terminal
B91016405
Montageclip Montageclip für Schaubmontage (1 Stk.) / Mounting clip for screw fixing (1 pc) B98060008
Normen
Die Serie ISOMETER® IR420 entspricht den folgenden
Gerätenormen:
• DIN EN 61557-8 (VDE 0413-8)
• EN 61557-8
• IEC 61557-8
