Appendix E
Compressor Application
Increasing Performance
Point
Total
360cc Single
720cc Dual
School Bus / RV / Air over Hydraulic
any
City Transit Bus / Highway Travel Coach /
Express Route Coach
any
School Bus Rural Route (No Auto Brake)
any
School Bus City Route (No Auto Brake)
any
Pick-up & Delivery
2.5 - 9
9.5 - 13
Line Haul
3 - 6
6.5 - 9
9.5 - 13
Rural or Commercial Refuse
6.5 - 9
Rural or Commercial Refuse / Yard or
Terminal Jockey
9.5 - 13
Residential Refuse (with Work Brake)
6.5 - 9
Residential Refuse (no Work Brake)
9.5 - 13
Concrete Mixer / Dump Truck /
Off-Highway / Construction / Logger
4 - 9
9.5 - 13
Fire Trucks
6.5 - 9
9.5 - 13
Bulk Off-loader
any
Central Tire Infl ation
any
Note: This compressor application matrix offers directional information when sizing a Bendix compressor for the applicable vehicle
vocation. Testing should still be performed on the specifi c application to verify that the compressor remains within the 25% maximum
allowable duty cycle. This application matrix assumes that all compressor installations use an air induction system that is naturally
aspirated. The “Compressor Installation & Application Review” form explains the methods used to measure the vehicle’s duty cycle.
Compressor
Selections
Point Totals
Bendix
®
360cc
compressor
Bendix
®
720cc
compressor
Points 2.5 3 4 5 6 6.5 7 8 9 9.5 10 11 12 13 14 15 16 or above
Certifi cation to all applicable vehicle regulations is the sole responsibility of the vehicle manufacturer.
The application chart is for reference only. If your truck/tractor does not fall into these guidelines, please contact the
Bendix Compressor Engineering or Technical Services team at 1-800-AIR-BRAKE.
