BENDIX EC-60 ABS User Manual

26
Active or Inactive Diagnostic Trouble Codes:
INDEX
How to interpret the first digit of messages received
when Active or Inactive Diagnostic Trouble Code Mode
is entered.
1st
Blink
Code
Number
1 ............................... No DTCs (1,1)
2 ..............Wheel Speed Sensors - pages 27-28
3 ..............Wheel Speed Sensors - pages 27-28
4 ..............Wheel Speed Sensors - pages 27-28
5 ..............Wheel Speed Sensors - pages 27-28
6 ........................Power Supply - page 29
7 ..........Pressure Modulator Valves - pages 30-31
8 ..........Pressure Modulator Valves - pages 30-31
9 ..........Pressure Modulator Valves - pages 30-31
10 .........Pressure Modulator Valves - pages 30-31
11 ..........................J1939 - pages 32-33
12 ...................Miscellaneous - pages 34-35
13 .............................. ECU - page 36
14 .............Wheel Speed Sensors - pages 27-28
15 .............Wheel Speed Sensors - pages 27-28
16 .........Pressure Modulator Valves - pages 30-31
17 .........Pressure Modulator Valves - pages 30-31
18 ........Drive Axle Traction Control Valve - page 37
19 ....... Steer Axle Traction Control Valve - page 37
20 .... Trailer Pressure Modulator Valve - pages 30-31
21 .............Steering Angle Sensor - pages 38-39
22 .................Yaw Rate Sensor - pages 40-41
23 ............Lateral Acceleration Sensor - page 42
24 .......... Brake Demand/Load Sensors - page 43
Example: For a message sequence of:
3, 2 12, 4
For the rst sequence go to page 27 and
for the second sequence go to page 34.
Go Here for Troubleshooting Tests
See Page 51 for APPENDIX B: J1587 SID and FMI Codes and their Bendix Blink Code Equivalents
See Page 56 for APPENDIX C: UDS Codes and their Bendix Blink Code Equivalents

BENDIX EC-60 ABS Specifications

General

Type	ABS Controller
Function	Anti-lock Braking System control
Model	EC-60
Manufacturer	Bendix
Operating Temperature	-40°C to +85°C
Compatibility	Heavy-duty Vehicles
