BENDIX EC-60 ABS User Manual

51
APPENDIX B: J1587 SID and FMI Codes and their Bendix Blink Code Equivalents
SID
(J1587)
SPN
(J1939)
FMI
(J1587/
J1939)
Bendix Blink Code
Equivalent(s)
Diagnostic Trouble Code Description
(1st Digit) (2nd Digit)
- - 1 1 No DTCs
Wheel Speed Sensor DTCs
1 789 1 2 1 SA Left WSS Excessive Air Gap
1 789 2 2 3 SA Left WSS Open or Shorted
1 789 7 2 5 SA Left WSS Wheel End
1 789 8 2 6 SA Left WSS Erratic Sensor Signal
1 789 10 2 4 SA Left WSS Loss of Sensor Signal
1 789 13 2 7 SA Left WSS Tire Size Calibration
1 789 14 2 2 SA Left WSS Output Low @ Drive-Off
2 790 1 3 1 SA Right WSS Excessive Air Gap
2 790 2 3 3 SA Right WSS Open or Shorted
2 790 7 3 5 SA Right WSS Wheel End
2 790 8 3 6 SA Right WSS Erratic Sensor Signal
2 790 10 3 4 SA Right WSS Loss of Sensor Signal
2 790 13 3 7 SA Right WSS Tire Size Calibration
2 790 14 3 2 SA Right WSS Output Low @ Drive-Off
3 791 1 4 1 DA Left WSS Excessive Air Gap
3 791 2 4 3 DA Left WSS Open or Shorted
3 791 7 4 5 DA Left WSS Wheel End
3 791 8 4 6 DA Left WSS Erratic Sensor Signal
3 791 10 4 4 DA Left WSS Loss of Sensor Signal
3 791 13 4 7 DA Left WSS Tire Size Calibration
3 791 14 4 2 DA Left WSS Output Low @ Drive-Off
4 792 1 5 1 DA Right WSS Excessive Air Gap
4 792 2 5 3 DA Right WSS Open or Shorted
4 792 7 5 5 DA Right WSS Wheel End
4 792 8 5 6 DA Right WSS Erratic Sensor Signal
4 792 10 5 4 DA Right WSS Loss of Sensor Signal
4 792 13 5 7 DA Right WSS Tire Size Calibration
4 792 14 5 2 DA Right WSS Output Low @ Drive-Off
5 793 1 14 1 AA Left WSS Excessive Air Gap
5 793 2 14 3 AA Left WSS Open or Shorted
5 793 7 14 5 AA Left WSS Wheel End
5 793 8 14 6 AA Left WSS Erratic Sensor Signal
5 793 10 14 4 AA Left WSS Loss of Sensor Signal
5 793 13 14 7 AA Left WSS Tire Size Calibration
5 793 13 14 10 AA Left WSS Conguration Error
5 793 14 14 2 AA Left WSS Output Low @ Drive-Off
6 794 1 15 1 AA Right WSS Excessive Air Gap
6 794 2 15 3 AA Right WSS Open or Shorted
6 794 7 15 5 AA Right WSS Wheel End
6 794 8 15 6 AA Right WSS Erratic Sensor Signal
6 794 10 15 4 AA Right WSS Loss of Sensor Signal
6 794 13 15 7 AA Right WSS Tire Size Calibration
6 794 13 15 10 AA Right WSS Conguration Error
6 794 14 15 2 AA Right WSS Output Low @ Drive-Off
Pressure Modulator Valve DTCs
7 795 5 7 7 SA Left PMV CMN Open Circuit
7 795 13 7 8 SA Left PMV Conguration Error
8 796 5 8 7 SA Right PMV CMN Open Circuit
8 796 13 8 8 SA Right PMV Conguration Error
9 797 5 9 7 DA Left PMV CMN Open Circuit
9 797 13 9 8 DA Left PMV Conguration Error
10 798 5 10 7 DA Right PMV CMN Open Circuit
10 798 13 10 8 DA Right PMV Conguration Error
11 799 5 16 7 AA Left PMV CMN Open Circuit
11 799 13 16 8 AA Left PMV Conguration Error
12 800 5 17 7 AA Right PMV CMN Open Circuit
12 800 13 17 8 AA Right PMV Conguration Error
