BENDIX EC-60 ABS User Manual

56
APPENDIX C: UDS Codes and their Bendix Blink Code Equivalents
UDS
Code
US-
Spec.
Blink
Code
J1587
PID194
(SID/
FMI)
J1939/73
DM1/2
SPN/FMI
DTC Description
Lamp
Status
ABS
ATC/
ESP
0 01-01 000-00 --- no DTC - -
1 14-03 005-02 0793-02 AA Left WSS Open or Shorted ON ON
3 14-10 005-13 0793-13 AA Left WSS Conguration Error ON ON
4 13-14 254-12 0629-12 ECU (04) ON ON
5 14-05 005-07 0793-07 AA Left WSS Wheel End ON ON
6 13-15 254-12 0629-12 ECU (06) ON ON
7 14-01 005-01 0793-01 AA Left WSS Excessive Air Gap ON ON
8 14-02 005-14 0793-14 AA Left WSS Output Low @ Drive-Off ON ON
9 14-06 005-08 0793-08 AA Left WSS Erratic Sensor Signal ON ON
10 14-04 005-10 0793-10 AA Left WSS Loss of Sensor Signal ON ON
13 13-17 254-02 0629-02 ECU (0D) ON ON
14 13-16 254-12 0629-12 ECU (0E) ON ON
15 12-14 103-02 1808-02 Sensor CAN Supply Voltage Error - ON
16 13-02 254-12 0629-12 ECU (10) ON ON
17 13-03 254-12 0629-12 ECU (11) ON ON
18 13-04 254-02 0629-02 ECU (12) ON ON
19 13-05 254-02 0629-02 ECU (13) ON ON
20 13-06 254-12 0629-12 ECU (14) ON ON
21 13-07 254-02 0629-02 ECU (15) ON ON
22 13-08 254-13 0630-13 ECU (16) ON ON
23 13-09 254-13 0630-13 ECU (17) ON ON
24 13-10 254-12 0630-12 ECU (18) ON ON
25 13-18 254-02 0629-02 ECU (19) ON ON
26 13-11 254-12 0802-12 ECU (1A) ON ON
27 13-12 254-12 0802-12 ECU (1B) ON -
28 13-19 253-12 0630-12 ECU (1C) - -
29 13-21 253-13 0630-13 ECU (1D) ON ON
30 13-22 253-13 0630-13 ECU (1E) ON ON
32 06-06 251-03 0627-03 Ignition Voltage Too High ON ON
33 06-05 251-04 0627-04 Ignition Voltage Too Low ON ON
34 06-07 251-04 0627-04 Ignition Voltage Too Low During ABS ON ON
35 06-02 251-03 0627-03 Battery Voltage Too High ON ON
36 06-01 251-04 0627-04 Battery Voltage Too Low ON ON
37 06-03 251-04 0627-04 Battery Voltage Too Low During ABS ON ON
38 06-04 251-05 0627-05 Battery Voltage Input Open Circuit ON ON
39 13-20 253-12 0630-12 ECU (27) ON ON
40 13-23 253-13 0630-13 ECU (28) ON ON
41 12-08 093-03 0802-03 PMV Common Shorted to Voltage ON ON
42 12-07 093-04 0802-04 PMV Common Shorted to Ground ON ON
43 11-07 231-02 0639-02 Timeout or invalid CAN data for ETC7/VP15 - -
44 11-04 231-02 0639-02 J1939 Invalid Data (Engine/Retarder) - ON
45 11-05 231-02 0639-02 J1939 Supply Pressure - ON
46 11-08 231-02 0639-02 Timeout or invalid CAN data - XBR - -

BENDIX EC-60 ABS Specifications

General

Type	ABS Controller
Function	Anti-lock Braking System control
Model	EC-60
Manufacturer	Bendix
Operating Temperature	-40°C to +85°C
Compatibility	Heavy-duty Vehicles
