BENDIX EC-60 ABS User Manual

57
APPENDIX C: UDS Codes and their Bendix Blink Code Equivalents
UDS
Code
US-
Spec.
Blink
Code
J1587
PID194
(SID/
FMI)
J1939/73
DM1/2
SPN/FMI
DTC Description
Lamp
Status
ABS
ATC/
ESP
48 12-05 013-03 0801-03 Retarder Relay Circuit Shorted to Voltage ON -
48 12-05 094-03 2622-03 Retarder Relay Circuit or Hill Start Assist Lamp Shorted to
Voltage
ON -
49 12-04 013-02 0801-02 Retarder Relay Open Circuit or Shorted to Ground ON -
49 12-04 094-02 2622-02 Retarder Relay Circuit or Hill Start Assist Lamp open or
Shorted to Ground
ON -
50 19-02 019-05 0807-05 TCV SA Solenoid Open Circuit ON ON
51 11-01 231-12 0639-12 J1939 Serial Link ON ON
52 11-02 231-14 0639-14 J1939 Retarder ON ON
53 11-03 231-02 0639-02 J1939 Engine Communications - ON
54 11-10 231-02 0639-02 Invalid Data from Transmission ON -
55 13-24 254-12 0629-12 ECU (37) - ON
56 19-01 019-04 0807-04 TCV SA Solenoid Shorted to Ground - ON
57 19-03 019-03 0807-03 TCV SA Solenoid Shorted to Voltage - ON
58 18-03 018-05 0806-05 TCV DA Solenoid Open Circuit - ON
59 18-01 018-04 0806-04 TCV DA Solenoid Shorted to Ground - ON
60 18-02 018-03 0806-03 TCV DA Solenoid Shorted to Voltage ON ON
61 18-04 018-13 0806-13 TCV DA Conguration Error ON ON
62 19-04 019-13 0807-13 TCV SA Conguration Error ON ON
63 11-11 231-02 0639-02 Timeout or invalid CAN data - AUX I/O - -
64 24-03 069-02 1059-02 Open or Shorted Load Sensor - ON
65 02-03 001-02 0789-02 SA Left WSS Open or Shorted ON ON
66 24-01 077-02 1067-02 Shorted Brake Demand Sensor (Primary CKT) Open - ON
67 24-02 078-02 1068-02 Shorted Brake Demand Sensor (Secondary CKT) Open - ON
68 24-04 077-11 1067-11 Plausibility Error Brake Demand Sensor - ON
69 02-05 001-07 0789-07 SA Left WSS Wheel End ON ON
70 24-05 077-02 1067-02 PS Supply Voltage Error - ON
71 02-01 001-01 0789-01 SA Left WSS Excessive Air Gap ON ON
72 02-02 001-14 0789-14 SA Left WSS Output Low @ Drive-Off ON ON
73 02-06 001-08 0789-08 SA Left WSS Erratic Sensor Signal ON ON
74 02-04 001-10 0789-10 SA Left WSS Loss of Sensor Signal ON ON
77 23-02 099-13 1809-13 LAS Calibration in Progress - ON
78 23-07 099-14 1808-14 Erratic ESP Sensor Signal - ON
79 21-02 089-13 1807-13 SAS Calibration in Progress - ON
80 21-01 089-13 1807-13 SAS Not Calibrated - ON
81 07-06 042-05 0795-05 SA Left PMV HLD Solenoid Open Circuit ON ON
82 07-04 042-04 0795-04 SA Left PMV HLD Solenoid Shorted to Ground ON ON
83 07-05 042-03 0795-03 SA Left PMV HLD Solenoid Shorted to Voltage ON ON
84 07-07 007-05 0795-05 SA Left PMV CMN Open Circuit ON ON
85 07-03 048-05 0795-05 SA Left PMV REL Solenoid Open Circuit ON ON
86 07-01 048-04 0795-04 SA Left PMV REL Solenoid Shorted to Ground ON ON
87 07-02 048-03 0795-03 SA Left PMV REL Solenoid Shorted to Voltage ON ON
88 21-08 089-09 1807-09 SAS CAN Timeout - ON
89 21-04 089-02 1807-02 SAS Signal Out of Range - ON
90 21-06 089-12 1807-12 SAS Invalid Signal - ON
