BENDIX EC-60 ABS User Manual

58
APPENDIX C: UDS Codes and their Bendix Blink Code Equivalents
UDS
Code
US-
Spec.
Blink
Code
J1587
PID194
(SID/
FMI)
J1939/73
DM1/2
SPN/FMI
DTC Description
Lamp
Status
ABS
ATC/
ESP
91 21-07 089-02 1807-02 SAS Gradient Error - ON
92 21-09 089-02 1807-02 SAS Long Term Calibration Error - ON
93 07-08 007-13 0795-13 SA Left PMV Conguration Error ON ON
94 21-03 089-02 1807-02 SAS Static Signal - ON
95 21-05 089-02 1807-02 SAS Signal Reversed - ON
96 21-10 089-02 1807-02 SAS Plausibility Check (Ref Yaw Rate) - ON
97 05-03 004-02 0792-02 DA Right WSS Open or Shorted ON ON
98 22-05 103-09 1808-09 YRS CAN Timeout - ON
99 22-01 103-02 1808-02 YRS Signal Out of Range - ON
100 22-03 103-02 1808-02 YRS Invalid Signal - ON
101 05-05 004-07 0792-07 DA Right WSS Wheel End ON ON
102 22-06 103-02 1808-02 YRS Static BITE Error - ON
103 05-01 004-01 0792-01 DA Right WSS Excessive Air Gap ON ON
104 05-02 004-14 0792-14 DA Right WSS Output Low @ Drive-Off ON ON
105 05-06 004-08 0792-08 DA Right WSS Erratic Sensor Signal ON ON
106 05-04 004-10 0792-10 DA Right WSS Loss of Sensor Signal ON ON
109 22-07 103-02 1808-02 YRS Dynamic BITE Error - ON
110 22-04 103-02 1808-02 YRS Gradient Error - ON
111 22-08 103-02 1808-02 YRS Fast Calibration Error - ON
112 22-09 103-02 1808-02 YRS Static Calibration Error - ON
113 10-06 045-05 0798-05 DA Right PMV HLD Solenoid Open Circuit ON ON
114 10-04 045-04 0798-04 DA Right PMV HLD Solenoid Shorted to Ground ON ON
115 10-05 045-03 0798-03 DA Right PMV HLD Solenoid Shorted to Voltage ON ON
116 10-07 010-05 0798-05 DA Right PMV CMN Open Circuit ON ON
117 10-03 051-05 0798-05 DA Right PMV REL Solenoid Open Circuit ON ON
118 10-01 051-04 0798-04 DA Right PMV REL Solenoid Shorted to Ground ON ON
119 10-02 051-03 0798-03 DA Right PMV REL Solenoid Shorted to Voltage ON ON
120 22-10 103-02 1808-02 YRS Normal Calibration Error - ON
121 22-11 103-02 1808-02 YRS Sensitivity Calibration Error - ON
122 22-12 103-02 1808-02 YRS Plausibility Check (Ref Yaw Rate) - ON
123 22-02 103-02 1808-02 YRS Sensor Reversed Signal - ON
124 22-13 103-02 1808-02 YRS Plausibility Error (Inside Model Based Limits) - ON
125 10-08 010-13 0798-13 DA Right PMV Conguration Error ON ON
126 22-14 103-02 1808-02 YRS Plausibility Error (Outside Model Based Limits) - ON
127 11-06 231-02 0639-02 J1939 ESP Messages Invalid Data - ON
128 13-13 254-12 0629-12 ECU (80) ON ON
129 03-03 002-02 0790-02 SA Right WSS Open or Shorted ON ON
130 06-08 251-02 0627-02 Input Voltage Excessive Noise (Temp.) ON ON
131 06-09 251-14 0627-14 Input Voltage Excessive Noise (Latched) ON ON
132 12-22 103-02 1808-02 ESP Sensor Voltage Out of Range - ON
133 03-05 002-07 0790-07 SA Right WSS Wheel End ON ON
134 24-06 077-07 1067-07 PS Not Calibrated - ON
135 03-01 002-01 0790-01 SA Right WSS Excessive Air Gap ON ON

BENDIX EC-60 ABS Specifications

General

Type	ABS Controller
Function	Anti-lock Braking System control
Model	EC-60
Manufacturer	Bendix
Operating Temperature	-40°C to +85°C
Compatibility	Heavy-duty Vehicles
