BENDIX EC-60 ABS User Manual

52
APPENDIX B: J1587 SID and FMI Codes and their Bendix Blink Code Equivalents
SID
(J1587)
SPN
(J1939)
FMI
(J1587/
J1939)
Bendix Blink Code
Equivalent(s)
Diagnostic Trouble Code Description
(1st Digit) (2nd Digit)
Miscellaneous DTCs
13 801 2 12 4
Retarder Relay or HSA Lamp Open Circuit
or Shorted to Ground
13 801 3 12 5 Retarder Relay Circuit or HSA Lamp Shorted to Voltage
17 576 14 12 3 Dynamometer Test Mode
17 614 14 12 9 ATC Disabled to Prevent Brake Fade
TCV DTCs
18 806 3 18 2 TCV DA Solenoid Shorted to Voltage
18 806 4 18 1 TCV DA Solenoid Shorted to Ground
18 806 5 18 3 TCV DA Solenoid Open Circuit
18 806 13 18 4 TCV DA Conguration Error
19 807 3 19 3 TCV SA Solenoid Shorted to Voltage
19 807 4 19 1 TCV SA Solenoid Shorted to Ground
19 807 5 19 2 TCV SA Solenoid Open Circuit
19 807 13 19 4 TCV SA Conguration Error
Miscellaneous DTCs
22 810 7 12 11 Wheel Speed Sensors Reversed on an Axle
23 811 2 12 6 ABS Dash Indicator Circuit DTC
Pressure Modulator Valve DTCs
42 795 3 7 5 SA Left PMV HLD Solenoid Shorted to Voltage
42 795 4 7 4 SA Left PMV HLD Solenoid Shorted to Ground
42 795 5 7 6 SA Left PMV HLD Solenoid Open Circuit
43 796 3 8 5 SA Right PMV HLD Solenoid Shorted to Voltage
43 796 4 8 4 SA Right PMV HLD Solenoid Shorted to Ground
43 796 5 8 6 SA Right PMV HLD Solenoid Open Circuit
44 797 3 9 5 DA Left PMV HLD Solenoid Shorted to Voltage
44 797 4 9 4 DA Left PMV HLD Solenoid Shorted to Ground
44 797 5 9 6 DA Left PMV HLD Solenoid Open Circuit
45 798 3 10 5 DA Right PMV HLD Solenoid Shorted to Voltage
45 798 4 10 4 DA Right PMV HLD Solenoid Shorted to Ground
45 798 5 10 6 DA Right PMV HLD Solenoid Open Circuit
46 799 3 16 5 AA Left PMV HLD Solenoid Shorted to Voltage
46 799 4 16 4 AA Left PMV HLD Solenoid Shorted to Ground
46 799 5 16 6 AA Left PMV HLD Solenoid Open Circuit
47 800 3 17 5 AA Right PMV HLD Solenoid Shorted to Voltage
47 800 4 17 4 AA Right PMV HLD Solenoid Shorted to Ground
47 800 5 17 6 AA Right PMV HLD Solenoid Open Circuit
48 800 3 7 2 SA Left PMV REL Solenoid Shorted to Voltage
48 795 4 7 1 SA Left PMV REL Solenoid Shorted to Ground
48 795 5 7 3 SA Left PMV REL Solenoid Open Circuit
49 795 3 8 2 SA Right PMV REL Solenoid Shorted to Voltage
49 796 4 8 1 SA Right PMV REL Solenoid Shorted to Ground
49 796 5 8 3 SA Right PMV REL Solenoid Open Circuit
50 796 3 9 2 DA Left PMV REL Solenoid Shorted to Voltage
50 797 4 9 1 DA Left PMV REL Solenoid Shorted to Ground
50 797 5 9 3 DA Left PMV REL Solenoid Open Circuit
51 797 3 10 2 DA Right PMV REL Solenoid Shorted to Voltage
51 798 4 10 1 DA Right PMV REL Solenoid Shorted to Ground
51 798 5 10 3 DA Right PMV REL Solenoid Open Circuit
52 798 3 16 2 AA Left PMV REL Solenoid Shorted to Voltage
52 799 4 16 1 AA Left PMV REL Solenoid Shorted to Ground
52 799 5 16 3 AA Left PMV REL Solenoid Open Circuit
53 799 3 17 2 AA Right PMV REL Solenoid Shorted to Voltage
53 800 4 17 1 AA Right PMV REL Solenoid Shorted to Ground
53 800 5 17 3 AA Right PMV REL Solenoid Open Circuit
For more Pressure Modulator Valve DTCs - see SIDs 66 and 93 below...
