BENDIX EC-60 ABS User Manual

53
APPENDIX B: J1587 SID and FMI Codes and their Bendix Blink Code Equivalents
SID
(J1587)
SPN
(J1939)
FMI
(J1587/
J1939)
Bendix Blink Code
Equivalent(s)
Diagnostic Trouble Code Description
(1st Digit) (2nd Digit)
Miscellaneous DTCs
55 1045 2 12 2 Stop Lamp Switch Defective
55 1045 4 12 27 Brake Lamp Input Mismatch with Brake Lamp Output
55 1045 7 12 1 Stop Lamp Switch Not Detected
Pressure Modulator Valve DTCs
66 1056 3 20 2 Trailer PMV REL Solenoid Shorted to Voltage
66 1056 3 20 5 Trailer PMV HLD Solenoid Shorted to Voltage
66 1056 4 20 1 Trailer PMV REL Solenoid Shorted to Ground
66 1056 4 20 4 Trailer PMV HLD Solenoid Shorted to Ground
66 1056 5 20 3 Trailer PMV REL Solenoid Open Circuit
66 1056 5 20 6 Trailer PMV HLD Solenoid Open Circuit
66 1056 5 20 7 Trailer PMV CMN Open Circuit
66 1056 7 20 8 PMV Conguration Error
For more Pressure Modulator Valve DTCs - see SID 93 below...
Brake Demand/Load Sensor DTCs
69 1059 2 24 3 Open or Shorted Load Sensor
77 1067 2 24 1 Shorted Brake Demand Sensor (Primary CKT) Open
77 1067 2 24 5 PS Supply Voltage Error
77 1067 7 24 6 PS Not Calibrated
77 1067 11 24 4 Plausibility Error Brake Demand Sensor
78 1068 2 24 2 Shorted Brake Demand Sensor (Secondary CKT) Open
Miscellaneous DTCs
79 1069 13 12 10 Tire Size Out of Range (Front to Rear)
Steering Angle Sensor DTCs
89 1807 2 21 3 SAS Static Signal
89 1807 2 21 4 SAS Signal Out of Range
89 1807 2 21 5 SAS Signal Reversed
89 1807 2 21 7 SAS Gradient Error
89 1807 2 21 9 SAS Long Term Calibration Error
89 1807 2 21 10 SAS Plausibility Check (Ref Yaw Rate)
89 1807 9 21 8 SAS CAN Timeout
89 1807 12 21 6 SAS Invalid Signal
89 1807 13 21 1 SAS Not Calibrated
89 1807 13 21 2 Steering Angle Sensor Calibration Not Finished
89 1808 13 22 15 YRS Sign Check Not Finished
Pressure Modulator Valve DTCs
93 802 3 12 8 PMV Common Shorted to Voltage
93 802 4 12 7 PMV Common Shorted to Ground
HSA DTCs
94 2622 2 12 4 HSA lamp shorted to ground or broken wire
94 2622 3 12 5 HSA lamp shorted to Voltage
94 2622 3 12 24 HSA solenoid shorted to Voltage (total shutdown)
94 2622 3 12 26 HSA solenoid shorted to Voltage (ATC & ESP shutdown)
94 2622 5 12 25 HSA solenoid shorted to ground or broken wire
94 2622 13 12 24 HSA solenoid shorted to Voltage
Lateral Acceleration Sensor DTCs
99 1809 2 23 1 LAS Signal Out of Range
99 1809 2 23 3 LAS Static Calibration Error
99 1809 2 23 4 LAS Long Term Calibration Error
99 1809 2 23 5 LAS Plausibility Error (Inside ECU-Specic Limits)
99 1809 2 23 6 LAS Plausibility Error (Outside ECU-Specic Limits)
99 1809 13 23 2 LAS Calibration in Progress
99 1808 14 23 7 Erratic ESP Sensor Signal
