APPENDIX B: J1587 SID and FMI Codes and their Bendix Blink Code Equivalents
SID
(J1587)
SPN
(J1939)
FMI
(J1587/
J1939)
Bendix Blink Code
Equivalent(s)
Diagnostic Trouble Code Description
(1st Digit) (2nd Digit)
Miscellaneous DTCs
102 564 3 12 13 HSA Solenoid Shorted to Voltage (high)
102 564 5 12 12 HSA Solenoid Shorted to Ground (Low) or Open circuit
103 1808 2 12 14 Sensor CAN Supply Voltage Error
103 1808 2 12 22 ESP Sensor Voltage Out of Range
Yaw Rate Sensor DTCs
103 1808 2 22 1 YRS Signal Out of Range
103 1808 2 22 2 YRS Sensor Reversed Signal
103 1808 2 22 3 YRS Invalid Signal
103 1808 2 22 4 YRS Gradient Error
103 1808 2 22 6 YRS Static BITE Error
103 1808 2 22 7 YRS Dynamic BITE Error
103 1808 2 22 8 YRS Fast Calibration Error
103 1808 2 22 9 YRS Static Calibration Error
103 1808 2 22 10 YRS Normal Calibration Error
103 1808 2 22 11 YRS Sensitivity Calibration Error
103 1808 2 22 12 YRS Plausibility Check (Ref Yaw Rate)
103 1808 2 22 13 YRS Plausibility Error (Inside ECU-Specic Limits)
103 1808 2 22 14 YRS Plausibility Error (Outside ECU-Specic Limits)
103 1808 2 22 16 Yaw Rate Sensor Vibration Detected
103 1808 9 22 5 YRS CAN Timeout
Miscellaneous
151 611 14 12 18 wheel speed sensor failure in previous power on cycle
154 614 3 12 23 i/o 2 or i/o 3 Shorted to Voltage
J1939 DTCs
231 639 2 11 3 J1939 Engine Communications
231 639 2 11 4 J1939 Invalid Data (Engine/Retarder)
231 639 2 11 5 J1939 Supply Pressure
231 639 2 11 6 J1939 ESP Messages Invalid Data
231 639 2 11 7 Timeout or invalid data on ETC7/VP15 (for HSA-function)
231 639 2 11 8 timeout or invalid data on XBR
231 639 2 11 10 Invalid Data From Transmisson
231 639 2 11 12 J1939 HSA switch error or unavailable
231 639 2 11 13 timeout or invalid data for ESP AWD operation
231 639 12 11 1 J1939 Serial Link
231 639 14 11 2 J1939 Retarder
Power Supply DTCs
251 627 2 6 8 Input Voltage Excessive Noise (Temp.)
251 627 3 6 2 Battery Voltage Too High
251 627 3 6 6 Ignition Voltage Too High
251 627 4 6 1 Battery Voltage Too Low
251 627 4 6 3 Battery Voltage Too Low During ABS
251 627 4 6 5 Ignition Voltage Too Low
251 627 4 6 7 Ignition Voltage Too Low During ABS
251 627 5 6 4 Battery Voltage Input Open Circuit
251 627 14 6 9 Input Voltage Excessive Noise (Latched)
