BENDIX EC-60 ABS User Manual

36
1st. Blink
Code
13
Location:
ECU
Troubleshooting Diagnostic Trouble Codes:
ECU
2nd
Blink
Code
Bendix
®
ACom
®
Software
Description
Repair Information
1 ECU DTC '02'
13-1 through 13-7: Check for damaged or corroded connectors. Check for damaged
wiring including power and ground wiring. Clear the trouble codes. If Diagnostic Trouble
Codes (DTCs) return, contact the Bendix Tech Team at 1-800-AIR-BRAKE (1-800-247-
2725) for further troubleshooting assistance.
2 ECU DTC '10'
3 ECU DTC '11'
4 ECU DTC '12'
5 ECU DTC '13'
6 ECU DTC '14'
7 ECU DTC '15'
8
Invalid ABS
Coguration
ECU DTC '16'
Codes 13-8 and 13-18:
Check the ECU for damaged or corroded connectors. Check for damaged wiring
including power and ground wiring. Clear the trouble codes. If one of these DTCs
return, contact the Bendix Tech Team at 1-800-AIR-BRAKE (1-800-247-2725) for further
troubleshooting assistance.
When troubleshooting either of these DTCs, it is important to inspect the ATR
valves used for full stability and — if they have a DTC — repair them rst.
Note: Never run an ECU self-conguration before completing the ATC repair
and clearing its DTC, or a misleading 13-8 or 13-18 DTC may result.
9 ECU DTC '17'
13-9 through 13-17: Check for damaged or corroded connectors. Check for damaged
wiring including power and ground wiring. Clear the trouble codes. If Diagnostic Trouble
Codes (DTCs) return, contact the Bendix Tech Team at 1-800-AIR-BRAKE (1-800-247-
2725) for further troubleshooting assistance.
10 ECU DTC '18'
11 ECU DTC '1A'
12 ECU DTC '1B'
13 ECU DTC '80'
14 ECU DTC '04'
15 ECU DTC '06'
16 ECU DTC '0E'
17 ECU DTC '0D'
18
Invalid ESP
Conguration
ECU DTC '19'
See 13-8 above... Additionally, a 13-19 DTC can be the result of a parameter le not
having been downloaded. To verify that vehicle-specic parameters have been loaded,
contact Bendix for more information at 1-800-AIR-BRAKE (1-800-247-2725).
19 ECU DTC '1C'
13-19 through 13-24: Check for damaged or corroded connectors. Check for damaged
wiring including power and ground wiring. Clear the trouble codes. If DTCs return,
contact the Bendix Tech Team at 1-800-AIR-BRAKE (1-800-247-2725) for further
troubleshooting assistance.
20 ECU DTC '27'
21 ECU DTC '1D'
22 ECU DTC '1E'
23 ECU DTC '28'
24 ECU DTC '37'
25
ECU Internal VIN
Mismatch
The ECU internally-stored VIN does not match the VIN of the vehicle. Ensure that the ECU
is installed on the correct vehicle. Verify ECU programming. Verify engine programming.

BENDIX EC-60 ABS Specifications

General

Type	ABS Controller
Function	Anti-lock Braking System control
Model	EC-60
Manufacturer	Bendix
Operating Temperature	-40°C to +85°C
Compatibility	Heavy-duty Vehicles
