Appendix B
APPENDIX B - BENDIX
®
WINGMAN
®
FUSION
™
SYSTEM COMPONENT SCHEMATIC
Mating Connector
TE 2-174046-2
Bendix
™
FLR‑20
™
Radar Sensor
Speakers
Vibrating Seat
Motors
Radio
Mute
Video
Telematics
Connection
Bendix
®
ESP
®
EC-80
™
Controller
Vehicle
Sensors
Bendix
™
Driver
Interface Unit
(DIU
™
)
Battery 12V
Ignition 12V
Ground
J1939
J1939
SafetyDirect
®
by Bendix CVS Web Portal Processor
4 - J1939 High / 3 - J1939 Low
8 - LSD Out (Radio Mute Request)
5 - J1939 High
6 - J1939 Low
3 - RS232 TX
4 - RS232 RX
11 - Speaker Right (-)
2 - Speaker Common (+)
10 - Speaker Left (-)
15 - Haptic Left
14 - Haptic Right
7 - Switch Input
1 - Battery
1 - Battery
GND (A)
9 - Ignition
9 - Ignition
RS232 TX (B)
3
8 - Ignition
5 - Ground
7 - Fusion Private Com. High / 2 - Fusion Private Com. Low
4
9
10
6 - J1939 Low
1 - J1939 High
8 - Ground
16 - Ground
RS232 RX (C)
6 - Fusion
™
Private Com. Low
13 - Fusion Private Com. Low
7 - Fusion Private Com. High
12 - Fusion Private Com. High
2
5
Bendix
™
AutoVue
®
FLC‑20
™
Camera
LDW
(Enable/
Disable) Switch
Disconnect Harness Here if
OBC/T is Not in Use.
(See SD-65-21025,
Section 1.4)
On Board Computer/
Telematics (OBC/T)
System
OBC/T
