B KY 96A, KY 97A
Rev 5, Apr 2003 MM 006-05674-0005.dwd Page 6-106
-----------------------------------------------------------------------------
SYMBOL PART NUMBER FIND NO DESCRIPTION UM -0000 -0001 -0099
-----------------------------------------------------------------------------
L404 013-00006-0001 FERR BEAD EA . . 1.00
L405 013-00006-0001 FERR BEAD EA . . 1.00
L406 999-09999-0098 PLACE HOLDER RF . . .00
L407 019-02084-0005 CH .22UH 10% EA . . 1.00
L408 013-00006-0001 FERR BEAD EA . . 1.00
L409 013-00006-0001 FERR BEAD EA . . 1.00
L410 019-02084-0001 CH .15UH 10% EA 1.00 . .
L410 019-02084-0005 CH .22UH 10% EA . 1.00 .
L411 019-02084-0029 CH 2.2UH 10% EA . . 1.00
L412 999-09999-0098 PLACE HOLDER RF . . .00
L413 999-09999-0098 PLACE HOLDER RF . . .00
L414 999-09999-0098 PLACE HOLDER RF . . .00
L415 013-00006-0001 FERR BEAD EA . . 1.00
Q401 007-00250-0000 XSTR 2N4427 EA . . 1.00
Q402 007-00483-0000 XSTR RF, POWER EA . . 1.00
Q403 007-00500-0000 XSTR RF 2SC1946A EA . . 1.00
Q404 007-00195-0000 XSTR S MPSH10 EA . . 1.00
R401 131-00182-0023 RES CF 1.8K QW 5% EA . . 1.00
R402 131-00471-0023 RES CF 470 QW 5% EA . . 1.00
R403 131-00300-0033 RES CF 30 HW 5% EA . . 1.00
R404 131-00100-0023 RES CF 10 QW 5% EA . . 1.00
R405 131-00100-0033 RES CF 10 HW 5% EA . . 1.00
R406 999-09999-0098 PLACE HOLDER RF . . .00
R407 999-09999-0098 PLACE HOLDER RF . . .00
R408 131-00103-0023 RES CF 10K QW 5% EA . . 1.00
R409 131-00100-0023 RES CF 10 QW 5% EA . . 1.00
R410 139-00511-0000 RES CH 51.1 EW 1% EA . . 1.00
R411 130-05101-0043 RES CHIP 100 HW EA . . 1.00
R412 130-05101-0043 RES CHIP 100 HW EA . . 1.00
REF1 300-07540-0000 5W TRANSMITTER BOA RF .00 . .
REF1 300-07540-0001 5W TRANSMITTER BOA RF . .00 .
REF2 002-07540-0000 SCH 14V TX BD KY 9 RF .00 . .
REF2 002-07540-0001 SCH KY96A 28V5WTXB RF . .00 .
T401 019-03026-0002 XFMR TW BIFLR EA . . 1.00
T402 019-03026-0003 XFMR TWISTED BIFLR EA . . 1.00
T403 019-03124-0001 XFMR BIFILAR RF 4T EA . . 1.00
009-08413-0000 KLX135 TX BD 14V EA . . 1.00
012-01127-0001 TAG COVER EA . . 4.00
016-01004-0000 COMPOUND THRML JNT AR . . 1.00
016-01008-0004 GLYPTAL 7526 BL AR . . 1.00
016-01071-0000 DC RTV 3140 AR . . 1.00
025-00004-0003 WIRE 20 ORN IN 10.30 10.00 .
025-00005-0002 WIRE 18 RED IN . . 6.00
025-00018-0089 WIRE 26 GY/WH IN . . 5.20
026-00003-0000 WIRE, CU, 22AWG, T IN . . 1.50
026-00004-0000 WIRE, CU, 20AWG, T IN . . 1.00
026-00013-0000 WIRE, COAX, RG-178 IN . . 7.00
030-00152-0000 CONN BNC HEX EA . . 1.00
073-00389-0014 TRANSMITTER HOUS EA . . 1.00
089-05901-0004 SCR PHP 3-48X1/4 EA . . 6.00
089-05903-0004 SCR PHP 4-40X1/4 EA . . 3.00
089-08033-0030 WASHER, INTERNAL L EA . . 1.00
090-00133-0001 HEATSINK .323 LG EA . . 1.00
091-00028-0000 SCREW, BINDER HD, EA . . 1.00
091-00155-0000 WASHER MICA EA . . 1.00
150-00103-0000 SLDR SLEEVE EA . . 2.00
200-07540-0099 KY96A/97A COM TXBD EA 1.00 1.00 .
