BENDIXKing KY 97A - KY 97 A (14 V) Modulator Assembly

B KY 96A, KY 97A
Rev 5, Apr 2003 MM 006-05674-0005.dwd Page 6-71
6.4.5 KY 97A (14V) Modulator Assembly
200-04270-0000 14V MODULATOR ASSY REV AA
---------------------------------------------------------------
SYMBOL PART NUMBER FIND NO DESCRIPTION UM -0000
---------------------------------------------------------------
C266 111-00001-0001 CAP CR .1UF 50V EA 1.00
Q124 007-00168-0000 XSTR PNP 2N4398 EA 1.00
REF1 300-04270-0000 COMM TRANSCEIVER K RF .00
RT101 134-01027-0000 POSISTOR BE EA 1.00
008-00050-0001 GND LUG EA 1.00
026-00004-0000 WIRE, CU, 20AWG, T IN 4.50
073-00388-0004 HEAT SINK 196A EA 1.00
076-00159-0000 SPACER INSUL EA 2.00
088-00829-0000 INSL EA 3.00
089-02013-0037 NUT FLAT 6-32 EA 2.00
089-05432-0003 SCR, MACH, 2-56, F EA 6.00
089-05907-0008 SCR PHP 6-32X1/2 EA 2.00
089-08016-0037 WSHR INTL LK #6 EA 1.00
089-08027-0011 WSHR FLT STD #6 EA 1.00
089-08080-0030 WSHR FLT STD .147 EA 2.00
091-00038-0000 WASHER EXT NY EA 2.00
091-00283-0002 TO-3 INSULATOR EA 1.00
150-00003-0010 TUBING TFLN 24AWG IN 4.00
150-00005-0010 TUBING TFLN 20AWG IN 7.25
